Gree EVO Series Unit Installation Guide

3
Unit Installation
3 Service Tools
Name Picture
Spanner
Screw Driver
Pliers
Tube Tongs
4 Instalaltion Instructions
4.1 Installation Examples
CASE 1: Connection of Terminals for Heating and Cooling (Under floor Loop, Fan Coil Unit, and
Radiator)
B
M
Under Floor Coil
FCU 1
T
Radiator
B
T
Bypass valve (field supplied)
High temperature line
Low temperature line
2-Way Vavle (field supplied)
Remote room thermostat (field supplied)
Controll Cable
M
FCU 2
