Gree GMV-121WL/C-T User Manual

GREE DC Inverter Multi VRF System II Service Manual
166
NO.
Name of Part
GMV-H280WL/A-X,GMV-280WL/C-X
Product Code
CN850W0340
CN850W0520
Part Code
Quantity
17
Front Grill
01574100008
2
18
Diversion Circle
10474100003
2
19
Handle
26235253
2
20
Chassis Assy
01194100112
1
21
Oil Separator
07424100050
1
22
Cut off Valve
07130208
1
23
Cut off Valve
07334100011
1
24
Compressor Gasket
76715019
4
25
Cut off Valve
07334100012
1
26
Compressor and Fittings
00204100023
1
27
Electric Heater(Compressor)
7651540714
1
28
Gas-liquid Separator
07424100048
1
29
Pressure Protect Switch
4602000902
1
30
Bidirection Strainer
07220016
1
31
Strainer
07415200002
1
32
Discharge Charge Valve Sub-Assy
07334100066
1
33
Discharge Charge Valve
07133771
1
34
Plate-type Heat Exchanger Assy
00904100029
1
35
Electronic Expansion Valve
43044100172
1
36
Electric Expand Valve Fitting
4304413204
1
37
Rear Side Plate
01314100092P
1
38
Inhalation tube Assy
04574100168
1
39
Electromagnetic Valve
43003091
1
40
Magnet Coil
4304000413
1
41
Electric Expansion Valve Sub-Assy
43044100237
1
42
Electronic Expansion Valve
43044100173
1
43
Electric Expand Valve Fitting
4304413205
1
44
4-Way Valve Assy
04044100081
1
45
Strainer
07414100026
1
46
4-way Valve
43000339
1
47
Strainer
07212121
1
48
Magnet Coil
4300040032
1
49
One way Valve
07335210
1
50
Nozzle for Adding Freon
06120012
1
51
Condenser Assy
01124100160
1
52
Rear Grill
01574100014
2
53
Gas By-pass sub- assy
04534100108
1
54
Magnet Coil
4304000416
1
55
Electromagnetic Valve
43000054
1
56
Sensor (High Pressure)
322101032
1
57
Sensor
322101002
1
58
One way Valve
04324001
1
Above data is subject to change without notice, pls reference the SP in global service website.

Gree GMV-121WL/C-T Specifications

General

Brand	Gree
Model	GMV-121WL/C-T
Category	Air Conditioner
Language	English
