Gree GU71P/A1-K User Manual

U-Match Series Duct Type Unit
6
2.2 Product Operating Range
Cooling
Heating
Outdoor temperature DB(°C)
-15~48
-15~24
Indoor temperature DB/WB(°C)
(Maximum)
32/23 27/-
2.3 Standard Accessories
Indoor Unit Accessories
No.
Name
Appearance
Q'ty
Usage
1 Wired Controller 1 To control the indoor unit
2 Nut with Washer 4
To fix the hook on the cabinet
of the unit
3 Nut 4
To be used together with the
hanger bolt for installing the
unit
4 Washer 4
To be used together with the
hanger bolt for installing the
unit
5 Insulation 1 To insulate the gas pipe
6 Insulation 1 To insulate the liquid pipe
7 Fastener 8
To fasten the sponge and the
Damping Block
8 Sponge 2 To insulate the drain pipe
9 Sponge 1 To insulate the Fresh air inlet
10 Nut 1 To connect gas pipe
11 Nut 1 To connect liquid pipe
12
Connecting
Tube Assembly
1
To connect gas pipe(Only
Unit 71)
