Installation Guide
Select of Install Location
Indoor Unit
The air inlet and outlet vent should far away from obstruction so that air can be blown to the entire room;
Select the place where is easy to drain condensate or easy to connect with outdoor unit;
Be far away from heat resource, steam and flammable gas;
Select the place where it is possible to stand the weight of indoor unit without increasing the running
noise and librations.
Ensure the install of indoor unit fits requirments on install dimension diagram;
Ensure there should be enough space for maintenance or repair, distance between indoor unit and floor
should be over 200cm;
Place the units to where should be 1m or more away from TV, Hi-fi and other appliances;
Place the unit to where air filter will be taken out easily.
Outdoor Unit
Outdoor unit should be installed on a firm stand to prevent increase of noise and shake.
Don't have the air outlet vents blocked.
When installing the unit on seashore or high altitude where there is strong wind, in order to maintain normal
run of fan, the unit should be installed against wall and baffle should be adopted.
In the area where there is strong wind, it is necessary to prevent wind from blowing into the air conditioner.
Don't install the outdoor unit in sealed space, it should be installed in where has good ventilation.
Notes :
Installation of the following places may cause malfunction; if it is unavoidable to install there,
please contact Gree Authorized Service Center.
Place where there is machine oil.
Saline and alkaline place where is near sea.
Place where there is sulfureted gas (such as sulfureted spring).
Place where there is high-frequency equipments such as radio,
welders and medical equipment.
Place in special ambient.
