◆ Install the indoor unit
☆
Install of rear panel
(Note: If there is no special indication, install of dual-split indoor unit is shown by
unit A, installation method of unit B is the same as that of unit A.)
1. Measure horizon by handing line or horizontal
measurement. since drainage pipe hole is on
left side, when adjusting panel, the left should
Rear pipe hole on right
Rear pipe hole of left
Ф50
Ф50
Fig. 1
2. Fix the rear panel on the selected location with screws.
3. Pull the rear panel by hand after installation to see if it is firm enough.
The rear panel should be able to stand the weight of an adult (60kg)
2. Do not wrench, bend or heave the hose or flood its
end by water.
☆ Open piping hole
1. Drill a hole outward at a slant after accertaining location piping hole as in fig.1（Ф５０）.
2. In order to prevent pipe and cable from damaging when going though the hole, install
☆ Install drainage hose
1. Drainage hose must be placed at a downward slant
3. The prolonged drainage hose should be wrapped with
Do not flood
Fig.2
Bent
Wrenched
▲
Connect connection pipes with indoor unit first and then outdoor unit.
▲
Bend the connection pipe carefully or it would be damaged.
▲
Don't tighten the joint nut too much or leakage would occur.
☆ Install connection pipe
Connect the connection pipe with 2 leading pipes from indoor unit, and then
Note:
☆ Electric wiring
1. Open panel upwardly;
2. Take off electric box cover;
3. Make power connect wire through wire hole at bottom case and bottom of
２２
never be highter; it is better to make it lower.
and the wight should be evenly shared by each screw.
wall sleeve.
for smooth drainage.
heat insulation material when going through indoor.
it in water
tighten the joint nuts on connection pipe.
Electric box cover
electric box from down to up.
