Service Manual
T
echnical Information
19
3.Outline Dimension Diagram
No obstacles within 1m at least in front of air outlet.
Model
W
H
D
07/09K
560
375
668
12K
660
428
700
18/21K
660
428
770
Unit:mm
More than 500mm
More
than
150mm
More
than
150mm
WD
H
21
23
