Service Manual
Technical Information
20
4.Refrigerant System Diagram
Cooling model
Cooling and heating model
OUTDOOR COILS
HOT DISCHARGED AIR
COMPRESSOR
REFRIGERANT FLOW DIRECTION
CAPILLARY
CENTRIFUGAL
OR CROSS FAN
AXIAL FAN
INDOOR COILS
COOLED AIR
OUTDOOR COILS
HOT DISCHARGED AIR
COOLED AIR
COMPRESSOR
AXIAL FAN
CENTRIFUGAL
CAPILLARY
OR CROSS FAN
REFRIGERANT FLOW DIRECTION
NOTES:
COOLING MODE
HEATING MODE
HOT AIR
INDOOR COILS
COOLED AIR
