Service Manual
Technical Information
29
6.2 Introduction of Remote Controller
This is a general use remote controller, it could be used for the air conditionerswith multifunction; For some function, which
the model doesn't
have, if pressthe corresponding button on the remote controller that the unit will keep the original running status.
1
2
3
4
5
7
6
9
8
+ / - button
On/Off button
Mode button
Swing button
Fan button
Sleep button
Timer button
Health button
WiFi button
Set fan speed
Set time
NOTICE:
“
do not. Please refer to the actual models.
Send signal
Sleep mode
Child lock
health function
ventilation operation
8ć heating function
Set temperature
Operation mode
Auto mode
Cool mode
Dry mode
Fan mode
TIMER ON /TIMER OFF
Heat mode
Light function
X-fan mode
Up & down swing
I feel function
” This is a general remote controller. Some models have this function while some
Temp. display type
:Indoor ambient temp.
:Set temp.
:Outdoor ambient temp.
Turbo mode
YAW1F7(WiFi)
