83
Air to Water Heat Pump
Service Manual- Versati II Series
MAINTENANCE
●
Parts List of GRS-CQ12Pd/NaB-K(O) for ER010W1130, GRS-CQ14Pd/NaB-K(O) for ER010W1140, and
GRS-CQ16Pd/NaB-K(O) for ER010W1150
No� Name of part Part code Quantity
1 Right Connection Board 01344100003P 1
2 Front Connection Board 01344100002P 1
3 Gas-liquid Separator 07425216 1
4 Electric Expand Valve Fitting 4304413221 1
5 Electronic Expansion Valve 07334412 1
6 Cut off Valve 07330000002 1
7 Cut off Valve 07330000001 1
8 Pressure Protection Switch 46020007 1
9 Gasket 76815204 3
10 Electrical Heater (Compressor) 765152123 1
11 Compressor and Fittings 00205224 1
12 Inductance 43120122 1
13 Electric Inductance Box 01424173 1
14 Drainage Connecter 06123401 1
15 Electrical Heater (Chassis) 765100041 1
16 Drainage Hole Cap 06813401 3
17 Fan Motor 1570411501 1
18 Axial Flow Fan 10338731 2
19 Front Side Plate 01314100012P 1
20 Handle 26235253 2
21 Cabinet 01514100002P 1
22 Diversion Circle 10474100001 2
23 Front Grill 01575200001 2
24 Left Side Plate 01314100013P 1
25 Fan Motor 15704115 1
26 Fan Motor Support Sub-assy 01802800138 1
27 Electric Box Assy 01392800080 1
28 Terminal Board 42011242 1
29 Overcurrent Circuit Breaker 46020018 1
30 Radiator 49010007 1
31 Electric Box 1 26904131 1
32 Filter Board 30228115 1
33 Main Board 30227000018 1
34 Electric Box Cover 01262800102 1
35 Coping 01264100008P 1
36 Magnetic Ring 49010109 1
37 Magnetic Ring 49010104 2
38 Condenser Assy 01122800043 1
39 Rear Grill 01574100004 1
40 Sensor Support 26905202 1
41 Sensor Sub-assy 39008000080G 1
42 Sensor (High Pressure) 322101032 1
43 Silencer 07245436 1
44 Strainer 07212121 2
45 Rear Side Plate Sub-assy 01314100011P 1
46 Nozzle for Adding Freon 06120012 1
47 Pressure Protection Switch 46020006 1
48 4-way Valve 43000338 1
49 Magnet Coil 4300040029 1
50 Strainer 07210037 1
To Next Page
