Page 12/43
Chart 5.2
J Do not install the machine near television antenna or any other antennas and antenna cables K Don’t install the
machine in the living area
L Be sure that the machine is out of the children’s reach
5.2 Installation Instructions
Note：Before installation, Please confirm whether it is the first install system or have already installed system after
installed the inverter, If it is the first install system, Please according to the installation manual of inverter,
Installing the inverter first, If not, Please installation as the following steps.
5.2.1 Installation Layout
The installation layout of energy storage machine at home as following：
The energy storage machine SP 2000 needs to install near bus position(The red line is sampling line of Sensor as
below, The wire length is 5m（no more than 15m）,Installation position needs to consider distance less it),
To Next Page
