Overall Cosmetic Check
1. Check shipping carton for any sign of damage.
2. Inspect PCS2, especially in areas where damage to the shipping
carton, if any, was found.
3. Inspect PCS2 cabinet and mounted assemblies for imperfections.
Internal W
orkmanship
1. Remove front and rear access panels to gain access to internal
components.
2. Check all electrical connections including ground straps.
3. Check all pneumatic lines for evidence of kinked lines.
4. Check for loose or missing mounting hardware.
Langua
ge Configuration
1. Power on the PCS2 in the Utilities mode of operation by pressing and
holding the PLASMA key while switching the power on. Hold the
PLASMA key until the Utilities menu appears on the display.
2. Select Configuration on the Utilities menu by pressing the MODIFY
PROGRAM key until the arrow points to Configuration, then press
the DRAW key. Toggle the write protect switch on the Processor Card
when instructed. (Remove rear access panel.)
3. Press the MODIFY PROGRAM key until the arrow points to
Language.
4. Select Language by pressing the DRAW key.
5. Press the MODIFY PROGRAM key until the arrow points to the
language desired.
6. Select the language by pressing the DRAW key.
7. Press the STOP key to exit Language Configuration
Chapter 5
Installation and Configuration
Initial
Inspection
Configuration
of Protocol
Parameters
