Hahnel Viper TTL User Manual

GB
2 Viper TTL - English
Viper TTL Controls
08
06
05
04
A B C
07
09
01
03
02
15 14 13 11
16
10
12
Transmitter
(A) Group A
(B) Group B
(C) Group C
(1) ON/OFF Switch
(2) SEL – select button
(3) Adjust Dial – To adjust
settings
(4) Lock wheel
(5) LCD
(6) Power / Status LED
(7) Hot shoe
(8) Test Button
(9) MicroUSB–rmware
update
Receiver
(10) Hot shoe
(11) Power / Status LED
(12) ON/OFF Switch
(13)MicroUSB-rmwareupdate
(14)Remotecontrolcable
socket
(15) Test Button
(16) Group A / B / C switch
