CONNECT SERIES SERVICE MANUAL
62
ENGLISH
Maintenance
Front Panel Removal
Note: Be sure power is isolated before removing from panel.
Step Picture Work instruction
7. Remove the valve cover
Unscrew the screws of the valve cover with
a screwdriver.
8. Remove the right side plate.
Unscrew the screws that connect the
right side plate to the electric box and the
screws around the right side plate.
9. Install the right side plate.
Screw up the screws around the right side
plate. Be careful to handle well the clasps
at the bottom of the right side plate.
10. Install the grill.
Attach the grill back in place and tighten
up the screws.
To Next Page
