A
Drain Outlet
B
Top of Washer
3. With the side of the bottom cover that is marked FRONT/UP toward the interior
and front of the washer, align the edges of the cover with the track in the
bottom of the washer.
4. From the front of the washer, slide the bottom cover fully into the track making
sure the edges of the cover are behind the tabs.
NOTE: When the cover is completely inserted into the track behind the
tabs, the hole for the screw will be
ush and aligned with the hole in the
cabinet bottom.
A
Bottom Cover
B
Screw Hole
C
Tabs
5. Using the screw (provided), fasten the bottom cover to the cabinet base.
6. If installing casters, continue with STEP 3 - INSTALL CASTERS (OPTIONAL). If
not installing casters, using two or more people, stand the washer upright.
STEP 3 - INSTALL CASTERS
(Optional)
NOTE: If you later decide to install casters, you must
rst lay the washer on its
side. See “STEP 2 - INSTALL BOTTOM COVER” for instructions on how to
correctly lay the washer on its side.
1. Using a at blade screwdriver, pry the rubber pads from the bottom of all four
washer legs.
14
ENGLISH
To Next Page
