Harman JBL EON ONE Compact User Manual

11
AUDIO OUTPUTS
The EON ONE Compact provides a 1/4" PASS THRU output for connecting to additional EON ONE Compact
loudspeakers� A 3�5mm (1/8") HEADPHONE output is also provided for additional monitoring options�
USB POWER PORTS
These ports can be used to charge a Bluetooth device or other portable music playback device during use� One
port provides 1A for low-amperage devices and the other provides 2A for USB devices requiring higher current�
PASS THRU output can
be connected to the line
input of another JBL
EON ONE Compact to
expand the system for
monitoring or higher
output capabilities
USB power ports

Harman JBL EON ONE Compact Specifications

General

Brand	Harman
Model	JBL EON ONE Compact
Category	Speakers
Language	English
