Service Parts
P43 Pellet
Beginning Manufacturing Date: N/A
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide model number
and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
3 Flue Tail Pipe 3-00-247237 Y
4 Auger Motor Cover 2-00-773843P Y
5 Auger Motor Shield 2-00-773815P Y
6 Differential Switch 3-20-6866 Y
7 Distribution Blower 3-21-33647 Y
8 Combustion Blower 3-21-08639 Y
Combustion Blower Mounting Screws (Pkg of 100)
Commonly required
for Combustion Blower
replacement
1-00-53483208
Fan Blade, 5” Double Paddle (Combustion Blower) 3-20-502221
Y
9 Rear Cover Left 2-00-773828-1P Y
10 Rear Cover Right 2-00-773828-2P Y
11 Comb Intake Weldment 1-10-08516S Y
12 Retainer Assembly 1-10-08533S Y
13 Ash Pan 1-10-7738108A Y
14 Ash Door Assembly
Pre 008168147 1-10-7738106A
Post 008168147 1-10-773904A
Wood Handle Pkg of 3 3-40-08746-3
15 Bolt on Hinge 2-00-06968B
16 Cast Door Frame 4-00-06800P
Cast Door w/Glass 1-10-06800A
17 Glass Panel w/Gasket 1-00-950133647 Y
18
Door Handle Assembly
1-00-453001 Y
Contains: Handle, 6 mm Washer, SHCS, handle, Elbow, Paw (Cast), SSS, Bhcs.
Wooden Handle w/Hardware, Load Door 1-00-00247 Y
19 Burn Pot Weldment 1-10-00675 Y
Flame Guide 3-00-03000 Y
Clean Out Cover 2 Sets 1-00-06623
Y
Thumb Screw Pkg of 10 3-31-782108-10 Y
20
Fire Brick 4-1/2 x 9 x 1-1/4” Pkg of 7 1-00-900450125 Y
Firebrick, Full Skid 414 Pcs 3-40-900450-414
21 Hopper Heat Shield 2-00-773854B
22 Feeder Cover 2-00-773826L
23 Circuit Board w/Knobs & Shafts 1-00-05886 Y
Control Board Label 3-90-07766
Circuit Board Plate, Studded w/label 1-10-08327
Knob, Contol Board/D-Shaft 25 Sets 1-00-015605 Y
Airwash O-Rings Pkg of 10 1-00-939639
Y
Arrow Burn Pot Scraper Pkg of 10 2-00-773850-10
Cradle Assembly
Igniter Holder, Cradle, & Flat Bottom
3 Sets 1-00-06620
Y
Additional service parts on following page.
