Troubleshooting (continued)
In the case that an internal failure has been detected, the Variable Speed Drive will turn the motor off and display a
corresponding error code listed below. As well, the power LED will “FLASH” continuously. If more than one error has
been detected the screen will flash between the errors.
The Variable Speed Drive is protected against overload and overheating. If such an error occurs, the controller
will automatically try to restart the motor six (6) times. After failing the sixth time to restart the display will show
the error message “Err20”.
The cause of an error should be investigated and resolved before continuing normal operation of the pump. When the
issue has been resolved, press the RUN/STOP key to clear the error message.
Variable Speed Drive Error Codes
Service Mode
When troubleshooting the pump or the pool system it may be useful to run the pump without other program functions
like default speed settings and timers. This can be achieved by setting the VSD into Service Mode.
To enter Service Mode remove the power from the pump. Hold down the DISP/FUNC button and then apply the power
to the pump. “tESt” will then be displayed on the screen before the motor RPM’s while all three speed LED’s will be
constantly flashing while the pump remains in Service Mode.
In this mode only the RPM of the motor can be changed between 600 rpm and 3000rpm and no speeds will be saved in
this mode.
To exit Service Mode simply cycle the power to the pump on and off.
30-LITINSB004 Rev-B
30-LITINSB004 Rev-B
Error
Number
Description
Action
Possible Action
01
Under Voltage. Please check mains supply.
1
1 = Drive Restart
2 = Drive Stop
3 = Drive Stop Special
02
Over Voltage. Please check mains supply.
1
04
Maximum temperature exceeded Power Module.
3
05
Over Temperature – Motor.
3
07
Maximum Current exceeded.
2
10
Current Measurement Fails Permanently.
2
20
Overload during Startup Process.
1
64
Internal Short Circuit Failure.
2
98
Internal Communication Failure
2
Action 1 = Drive Restart: - When the error is detected the Error code is to be displayed on the screen for 3seconds
before initiating a Drive Restart. If the pump is configured in “RS485 Controlled” mode, it will only start if a speed
signal is being sent from the Hayward control system.
Action 2 = Drive Stop: - For any errors where the action is to “Stop” the Drive, the motor is to remain stopped
while displaying the error code(s) until the user presses the RUN/STOP key to re-set, or the power to the motor is
cycled off and back on. If the Drive is stopped due to multiple errors, the display shall scroll between each error
displaying each error for 3 seconds whilst blinking on and off every second before moving to the next error code and
repeating in a l
oop until the user presses the RUN/STOP key to re-set, or the power to the motor is cycled off and back on
Action 3 = Drive Stop Special: - For “Error 04 Maximum temperature exceeded Power Module”, or “Error 05
Over Temperature – Motor”, the Drive is to stop the motor and only allow it to restart once both of the over
temperature situations have cooled to a pre- determined safe level. The display is to show the fault code and then
proceed to the screens “ a ut o ” and “r s t r t” displaying each for 3 seconds. This will constantly loop around until a
favourable re-start condition is sensed by the int
ernal temperature probes.
If the pump is configured in “RS485 Controlle d” Mode, it will only start if a speed signal is being sent from the
Hayward control system.
