Page 5
Electrical - specifications
The Variable Speed Drive is fully electronic. Consisting of an integrated power module (IPM) and controller, hard and
software with a digital signal processor (DSP). The mains inputs are supplied with a power factor correction (PFC) and
EMC filters. The Variable Speed Drive controls a Totally Enclosed, Fan Cooled, Permanent Magnet Motor.
• Voltage: 220 - 240 VAC ± 10% of the mean rated voltage while running, 50Hz Single Phase
• Current: 7.8 amps
• Power (output): 1,400 W
• Speed Range: 600-3000 rpm
• Ambient temperature: 0 to 40°C
• Protection class: IP X5
All conductive parts within and around the pool shall be connected together by equipotential bonding conductors and
connected to the protective earthing conductor of the electrical equipment as stated in AS/NZS 3000.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
TriStar Variable Speed Pump
Only use Teflon tape or an elastomeric thread sealant suitable for plastic, to seal threaded connections on moulded
plastic components. All plastic fittings must be new or thoroughly cleaned before use.
Note - Do Not use Plumbers Pipe Dope or Plumbers Putty as it may cause cracking of the plastic components.
The pump suction and outlet ports have moulded in-thread stops. Do NOT attempt to force threaded connector fitting
past this stop. It is only necessary to tighten fittings enough to prevent leakage. Tighten fitting by hand and then use a
tool to engage the fitting an additional 1½ turns. Do NOT over-tighten fitting or you may cause damage. If a leak occurs,
remove the fitting and remove all traces of the sealing compound from thread. Re apply fresh sealing compound and
re-install the threaded fitting.
Note - If the pump is being installed using the standard Hayward Universal Union that is supplied with the pump
then there is no need to apply any type of thread sealant. The union gasket supplied is suffice to seal.
Fittings (elbows, tees, valves, ect.) restrict flow. For better efficiency use the fewest possible fittings. Avoid fittings that
could cause an air trap.
WARNING – Risk of Electric Shock. All electrical wiring must be performed by a qualified electrical
contractor, and must conform to electrical regulations and AS/NZS 3000 Wiring Rules. All electrical circuits must be
supplied through a Residual Current Device - RCD (Safety Switch), with a residual operating current of 30mA. Hazardous
voltage can shock, burn and cause death or serious property damage. To reduce the risk of electric shock, do NOT use
an extension cord to connect unit to the electricity supply, or if the supply cord is damaged, it must be replaced by the
manufacture, its service agent or similarly qualified persons in order to avoid a hazard.
Plumbing
Electrical
Bonding
WARNING - If circulation equipment must remain in the plumbing system during water pressure test, do
not apply more than 68 Kpa (10psi) pressure to the system. Be sure water pressure has been released, using the filter
manual air relief valve, before removing the pump strainer cover.
