13
This menu will appear only if Valve3 is configured for timeclock. The valve will rotate on and
off at the designated times. There is no manual override. If the Valve3 relay is on during the
programmed off time, it may be because of freeze protection.
Super Chlorinate
24 hours
+
>
>
Adjust Superchlorination period (1 - 96 hours)
Move to previous/next menu item
Larger pools or when you have an unusually high bather load, a large amount of rain, a
cloudy water condition, or any other condition that requires a large amount of chlorine to be
introduced to the pool, may require more hours of Superchlorination. Smaller pools require
less hours of Superchlorination.
Configuration Menu
The Aqua Logic MUST BE CONFIGURED before attempting to operate. Configuration information is
entered at the keypad and “tells” the Aqua Logic what equipment is connected and how each should be
controlled.
!
CAUTION: When changing an existing configuration, it is important to understand how
the pool system operates and what specific equipment is connected to each output. Incor-
rect settings in the configuration menu could lead to damaged equipment and improper
operation of the pool system.
Accessing the Configuration Menu
Configuring the Aqua Logic requires that you navigate through the Configuration Menu and input various
information. For more detailed information about using the Aqua Logic menu system, refer to the Opera-
tion Manual.
To access the Configuration Menu
Configuration
Menu-Unlocked
Configuration
Menu-Locked
Press repeatedly until “Configuration Menu” is displayed
Move to configuration menu items
Press BOTH buttons SIMULTANEOUSLY for 5 seconds to unlock
Menu
>
>
>
>
NOTE: The configuration menu automatically “locks” after 2 minutes of no buttons being
pressed to prevent unauthorized people from changing the control logic inadvertently and
possibly damaging the pool equipment or causing a “call back” to fix the configuration.
Set Day and Time
Wednesday 10:37P
+
>
>
Adjust time setting
Move between start and stop times & to previous/next menu item
Valve3-all
8:30A to 4:00P
+
>
>
Adjust time s
Valve3-wkend
8:30A to 4:00P
Valve3-wkday
8:30A to 4:00P
+
+
>
>
>
>
Adjust time setting
Adjust time setting
Move between start and stop times & to previous/next menu item
Move between start and stop times & to previous/next menu item
or
