Hayward Goldline Controls Aqua Logic AQL-P-4 User Manual

32
Diagnostic Menu
To enter the Diagnostic Menu, press the “Menu” button repeatedly until the display shows “Diagnostic
Menu”. At this point, you can use either the “<” or “>” buttons to scroll through the various menu items
which are described below:
Set Day and Time
Wednesday 10:37P
+
>
>
Move to previous/next menu item
+23.45 +6.75A
84°F 3200PPM
+
>
>
Press to switch chlorinator operation to opposite polarity (15 second delay)
+/- 23.45V is the voltage applied to the chlorinator cell
+/-6.75A is the current (amps) through the cell
84ºF is the water temperature at the cell
3200PPM is the “instant” salt level at this time
This display will be shown only if the chlorinator is enabled. For the chlorinator to be
operating, several other things must be happening: the filter pump must be running, the flow
switch must be detecting flow, the chlorinator setting must be set greater than 0%, the water
temperature at the cell must be between 50ºF and 140ºF, and the salt level must be within the
operating range. If any of these conditions are not met, the chlorinator diagnostic display
will tell you the reason. It’s possible to have more than one reason, in which case after you
rectify what was displayed the first time, a second display will appear.
If the current (amps) display is 0.00A, then the chlorinator is operating normally but is in the
off part of its normal operating cycle. Simply press either the “+” or “-“ key to start a new
cycle.
The Aqua Logic periodically reverses the polarity of the voltage applied to the cell in order
to automatically clean off any calcium deposits. It is important that you check the chlorinator
operation in both polarities. To do this, press either the “+” or “-“ buttons and the chlorinator
will turn off, wait for 15 seconds and then turn on in the opposite polarity.
If a conventional or solar heater is operating, it is likely that the temperature of the water at
the cell is higher than the pool/spa water temperature displayed on the Aqua Logic default
display.
Instant Salt
3200 PPM (+=save)
>
>
Move to previous/next menu item
+
Press to load the “Instant salt” into the averaged salt display
This display will be shown only if the chlorinator is enabled. This display shows “Instant
Salt” or “Instant Minerals” (if Chlor. Config. is set for “Display Minerals”). The “Instant
Salt” is calculated based on the voltage, current (amps), and water temperature at the cell.
This is different than the “average salt” value which is displayed as part of the default menu.
There are a number of reasons why instant and average salt readings may differ. Some of
these include salt having just been added to the pool and not yet thoroughly mixed, calcium
buildup on the cell, and the cell aging.
Flow Switch
Flow
+
>
>
No function
Move to previous/next menu item
This display will be shown only if the chlorinator is enabled. The current status of the flow
switch is displayed. There is a short delay when transitioning from flow to no-flow and a
longer delay on the transition from no-flow to flow. The delay time is displayed.
