Heat & Glo Curve 100S-HS User Manual

Curve Series
14      Heat&Glo•7076-108     2/11/2014
A. Ash Drawer
(Figure 14.1)
Before attempting any maintenance on the unit ensure
thattheunitiscoldandhasnoembersintherebox.To
access the ash drawer open the glass front. The drawer is
locatedundertherebox.Beforeremovingpanemptyash
fromreboxintothepan.
Todothisopenthegrateatthebottomoftherepot
usingarestokingtoolandslidingthetopgratecounter-
clockwise until all holes are open. Then gently sweep ash
through the grate into the ash drawer below. Then, using
stoking tool again, close the grate so that only the two small
holes in the back of the unit are open.
Then remove the ash pan drawer and empty into
noncombustible container. Never attempt to open ash pan
when stove is lit.
Figure 14.1 Ash Drawer Maintenance
Turngratecounter-clockwisetoopenallgrates.
Afterallholesopenpushashthroughgratesto
drawer below.
Remove drawer by pulling out and empty into
qualiedcontainer.
6
Maintenance
B. Refractory
Thereboxislinedwithmoldedrefractoryrebrick.The
refractory protects the outside of the appliance and retains
theheatnecessaryforacleanefcientburn.Thematerial
is a porous ceramic material that can break from abuse.
Occasionally, surface cracks may propagate from normal
use through the heating and cooling cycle. Surface cracks
are normal and should only be a concern when the crack
causes the refractory to not remain in place on its own.
C. Bafe Material
Therearetwobafeplatesinthetopoftheunit.The
purpose of these plates is to restrict and direct the
combustion gases to allow for complete combustion of the
gassespriortoexitingthereboxandenteringtheue.
Thelowerbafeplateissupportedonthesidesbytwo
steel pins and in the rear by resting on the back refractory
panel.
Theupperbafepanelissupportedbytwobrackets,one
oneachsideofthetopoftherebox.Duringannual
chimneymaintenance,thesetwobafepanelsmustbe
removedpriortosweeping.Notdoingsowillresultin
broken panels. Similar to the refractory panels lining the
insideoftherebox,thebafepanelsaresubjecttowear
and tear and are subject to warranty limitations.
D. Proper Burn
• Removeashfromreboxandashpanregularlyto
ensure proper air supply
• Useonly1-3piecesofwoodquarteredandplaced
tooptimizeairow(seeFigure01)
• Adjusttheupperaircontroltoensurethatenough
airisbeingsuppliedtotherebox,thereshould
alwaysbeavisibleamewithminimalsmoke
• Fuelshouldneverbestackedabovetheupperair
inlets(seeFigure01)
E. Coated Surfaces
Tocleanthestovedustwithalint-freeclothorcleaning
device. If the topcoat is damaged it is possible to purchase
a repair spray from your local dealer. It is possible that this
spraymaybeslightlydifferentfromtheoriginalcoat.For
best results, use repair spray in wide area in order to create
asubtletransitionfromonecolortothenext.Forsafety
purposes apply spray when stove is cold, the difference in
colormaybeverynoticeablewhenrstapplied.However,
afterringagainitshouldmatchveryclosetooriginalcolor.
F. Cleaning the Glass
Thisstoveisdesignedtominimizedsootbuild-up.To
attain this the stove must be burned properly, see section
For Proper Burn. However even when burned properly a
slight buildup of soot can occur. To clean you can use dry
cloth and regular glass cleaner or specialized stove glass
cleaning products.
