Curve Series
2/11/2014 Heat&Glo•7076-108 5
A. Positioning Your Wood Burning Stove
Thewoodburningstovemustbesetupsothestove,ue
connection,uepipe,andchimneysystemcanbecleaned
and serviced. Consideration should also be made when
locating the appliance in the home due to the supply of
combustion air requirements. Depending on the chosen
installation method, supplied combustion air may be taken
from the outside using the adapters provided, or through
the back of the unit by removing the cover plate on the
inlet hole. (To remove the cover or install the outside air
adapter, remove the back panel. The cover plate is located
near the bottom and retained with four screws.)
Out of the box, the appliance without the additional weight
of the venting system or fuel load weighs nearly 100
kilograms.Makeconsiderationsfortheweightofthe
system when locating the unit in the desired location. If
theloadbearingcharacteristicsofthestructurearedifcult
to determine or there is concern that the structure will not
adequately support the system, a distribution plate should
be used. Contact your Curve Wood Stove dealer with
questions.
B. Vertical Venting & Combustion Air
When venting the appliance vertically, follow the venting
manufacturer’s instructions and requirements. Slip the
coverringdowntheueandsetontopoftheappliance.
Vertical Venting Options (Fig. 5.1)
Standard 150mm Venting: G, E, B
Coaxialventing:F,E,D,A
(Use the items indicated for your installation. Use the bolts
provided to attach the components in the order shown.)
WheninstallingGorF:
• -Ifinstallingoutsidecombustionair,turnGorFto
cover the opening at the top of the combustion air
plenum.
• -Ifusingroomcombustionair,turnGorFtoleavethe
opening at the top of the combustion air plenum open.
(The outside air connection is located on the lower back
ofthestove.The75mmadapterisincludedinthe
component pack.)
C. Horizontal Venting
When venting the unit horizontally, remove the back panel
oftheunit.Next,removethecastueattachmentring
in the top of the appliance using the four bolts used to
secure it in shipping. Remove the rear cover plate that
can be seen in the back of the unit once the back panel is
removed. Install the rear cover plate over the vertical outlet
hole in the top of the unit using the four bolts that were
used to secure the cover plate when installed on the rear
oftheunit.Installthecastueattachmentringontherear
ofapplianceusingfourbolts.Knockoutthetwopanelson
2
Installation & Assembly
Opening at the top of the
combustion air plenum
A
B
C
D
E
F
G
thebackpanelsotheueattachmentringcanslipthrough
it.Attachthebackpanelbackontotheapplianceusing
the same fasteners. Install the venting per the venting
manufacturesspecications.Placethetopcoverplate
(item“C”inFig.5.1)fromthecomponentpackoverthe
holeinthetopoftheapplianceforanishedlook.
Thisunitissuitableforinstallationinasharedue.
Fig. 5.1
Fig. 5.2
