Heat & Glo Curve 100S-HS User Manual

Curve Series
4      Heat&Glo•7076-108     2/11/2014
A. Installation
The house owner is responsible for ensuring that all neces-
sary national and local safety measures are observed during
installationandttingandalsoresponsibleforobservingthe
ttingandoperatinginstructionsdetailedinthismanual.
Whenyouinstallanykindofreplaceorstove,youmust
informthelocalauthorities.Youarealsoresponsibleforcall-
ing in a chimney sweep to inspect and authorize the instal-
lation.
To ensurebest-possible functionalityand safety foryour
installation,we adviseyou tocall aprofessionaltter. Our
Hearth and Home Dealer will be able to recommend a quali-
edtterinyourarea.ForinformationonHearthandHome
Dealers, please go to www.hearthnhome.com.
Asareminder,alllocalregulations,includingthoserefer-
ring to national and European Standards need to be com-
plied with when installing the appliance.
B. Safety
Anychangesmadetotheproductbythedealer,installer
or user could result in the product and safety functions not
functioning as intended.The same applies to the tting of
accessories or extra equipment not supplied by Hearth and
Home. This could also be the case if parts that are neces-
sary for the operation and safety of the stove are dismantled
or removed.
External surfaces of the appliance get hot during use and
can cause burns. Use caution around the unit even when
the unit does not appear to be in use. Different materials
can hold heat for different lengths of time.
Intheeventofachimneyre,keepthefrontdoorclosed,
close all air controls, evacuate the structure and call the
local authorities from a safe location.
C. Type plates
AllHeat&Glowood-burningstovesarettedwitha
serialplate,thatspeciestheapprovalstandardsand
thedistancetoammablematerials.
Technical data and dimensions
Materials: steel plate, cast iron, galvanized sheet, skamol
Max.woodlength:25cm
WeightCurve100:ca.98kg
WeightCurve300:ca.96kg
Weightheat-accumulatingstones:ca.86,5kg
Connectingpieceinternaldiameter:135mm
Connectingpieceexternaldiameter:148mm
Approvaltype:Intermittentfuelling
Test in compliance with EN 13240
Basic data for the Curve - series
COEmissionat13%O2:.18%2262mg/Nm3
Dust@13%O2:14mg/Nm3
Nox@13%O2:70mg/Nm3
Nominaloutput:8.7kW
Amountofsmoke:5.6g/s
Sub-pressureEN13240:11.8Pa
Recommendedsub-pressureinconnectingpiece: 14-20Pa
Requiredcombustionairsupply:15.5Nm3/h
Fuel:  Wood
Fuelconsumption:2.68kg/h
Amountoffuel:2.10kg
Curve 100
Efciency:     74%
ChimneytemperatureEN13240:410°C
Temperatureinconnectingpiece:410°C
Curve 300
E f  c i e n c y :              7 4 % 
ChimneytemperatureEN13240:410°C
Temperatureinconnectingpiece:410°C
Intermittent fuelling means normal use of a wood stove. In
otherwords,youshouldlettherediedownuntilonlythe
embers are left, before refuelling.
The EC declaration of conformity is available from www.
hearthnhome.com
Note: Be aware of the use of exhaust fans when operating
in the same room or space as the appliance, which could
affect the draft of the appliance.
1
Technical Data
