Hikmicro THUNDER 2.0 Series User Manual

Thermal Image Scope User Manual
11
Chapter 3 Image Settings
3.1 Adjust Diopter
Steps
1. Power on the device.
2. Hold the device and make sure the eyepiece covers your eye.
3. Adjust the diopter adjustment ring until the OSD text or image is clear.
Figure 3-1 Adjust Diopter
Note
When adjusting diopter, DO NOT touch the surface of lens to avoid smearing the lens.
3.2 Adjust Focus
Steps
1. Power on the device.
2. Open the lens cover.
3. Hold the device and make sure the eyepiece covers your eye.
4. Adjust the focus ring/knob until the image is clear.
Note
When focusing, do not touch the surface of lens to avoid smearing the lens.

Hikmicro THUNDER 2.0 Series Specifications

General

Pixel Pitch	12 μm
Frame Rate	50 Hz
Video Recording	Yes
Photo Capture	Yes
Wi-Fi	Yes
Resolution	384x288 / 640x512
Objective Lens	19mm / 25mm / 35mm / 50mm
Battery Type	Rechargeable Li-ion
Digital Zoom	1x
Spectral Range	8 μm to 14 μm
