HIKVISION DS-2CD7153-E User Manual

User Manual of Digital Video Recorder
6
Product Key Features
General
 Connectable to HD-TVI and analog cameras;
 Connectable to the Coaxitron camera/dome with long transmission distance;
 Connectable to IP cameras from certain company;
 Each channel supports dual-stream. Main stream supports up to 1080P resolution and sub-stream
supports up to WD1 resolution;
 Independent configuration for each channel, including resolution, frame rate, bit rate, image quality,
etc.
 Encoding for both video stream and video & audio stream; audio and video synchronization during
composite stream encoding;
 Watermark technology;
Local Monitoring
 Simultaneous HDMI, VGA and CVBS outputs (no CVBS output for FT series);
 HDMI output and VGA output at up to 1920*1080 resolution;
 1/4/6/8/9/16 screen live view is supported, and the display sequence of screens is adjustable;
 Live view screen can be switched in group and manual switch and automatic cycle live view are also
provided, the interval of automatic cycle can be adjusted;
 Quick setting menu is provided for live view;
 The selected live view channel can be shielded;
 Motion detection, video-tampering detection, video exception alarm and video loss alarm functions;
 Privacy mask;
 Several PTZ protocols supported; PTZ preset, patrol and pattern;
 Zooming in/out by clicking the mouse and PTZ tracing by dragging mouse;
HDD Management
 4/8CH CF series, up to 2 SATA hard disks can be connected;
 8 network disks (8 NAS disks, or 7 NAS disks+1 IP SAN disk) can be connected.
 Support eSATA disks for recording or backup.
 Support S.M.A.R.T. and bad sector detection.
 Support HDD standby function;
 HDD property: redundancy, read-only, read/write (R/W).
 HDD group management;
 HDD quota management; different capacity can be assigned to different channels.
Recording and Playback
 Holiday recording schedule configuration;
 Cycle and non-cycle recording modes;
 Normal and event video encoding parameters;
 Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm;
 8 recording time periods with separated recording types;
 Pre-record and post-record for motion detection triggered recording, and pre-record time for schedule
and manual recording;
 Searching record files by events (alarm input/motion detection);

HIKVISION DS-2CD7153-E Specifications

General

Type	IP security camera
PTZ control	-
Day/night mode	Yes
Placement supported	Outdoor
Connectivity technology	Wired
Form factor	Dome
Product color	White
Protection features	Vandal proof
International Protection (IP) code	IP66
Total megapixels	2 MP
Maximum resolution	1600 x 1200 pixels
Supported video modes	720p
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	1280 x 960, 1280 x 720 (HD 720), 1600 x 1200 (UXGA)
Pan range	-15 - 15 °
Tilt angle range	0 - 90 °
Angle of rotation	15 °
Camera shutter speed	1/25 - 1/100000 s
Minimum illumination	0.1 lx
Field of view (FOV) angle	68 °
Sensor type	CMOS
Optical sensor size	1/3 \
Optical zoom	- x
Focus adjustment	1.8
Fixed focal length	2.8 mm
Password protection type	User
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP
Ethernet LAN (RJ-45) ports	1
DC output voltage	+12V
Power source type	PoE
Power consumption (max)	4 W

Weight and Dimensions

Depth	97.5 mm
Width	99.9 mm
Height	46.5 mm
Weight	250 g
