HIKVISION DS-2DE3304W-DE User Manual

User Manual of Network Mini PTZ Camera
© Hikvision
36
Full-screen Mode:
You can double-click on the live video to switch the current live view into full-screen
or return to normal mode from the full-screen.
3D Positioning:
Steps:
1. Click on the toolbar of live view interface.
2. Operate the 3D positioning function:
 Left click a position of the live video. The corresponding position will be
moved to the center of the live video.
 Hold down the left mouse button and drag the mouse to the lower right on
the live video. The corresponding position will be moved to the center of the
live video and zoomed in.
 Hold down the left mouse button and drag the mouse to the upper left on
the live video. The corresponding position will be moved to the center of the
live video and zoomed out.
Please refer to the following sections for more information:
 Configuring remote recording in Section 8.3 Configuring Recording Schedule.
 Setting the image quality of the live video in Section 7.1 Configuring Local
Parameters and Section 7.4.1 Configuring Video Settings.
 Setting the OSD text on live video in Section 7.5.2 Configuring OSD Settings.
5.4 Recording and Capturing Pictures Manually
In the live view interface, click on the toolbar to capture the live pictures and the The
captured image will be saved as a JPEG file in your computer by default.
You can click to record the live video.
The local saving paths of the captured pictures and clips can be set in the
Configuration > Local Configuration interface, and the image format can also be
edited in that interface.
To configure remote automatic recording, please refer to Section 8.3 Configuring
Recording Schedule.

HIKVISION DS-2DE3304W-DE Specifications

General

IK code	IK10
Form factor	Dome
Mounting type	Ceiling/wall
Product color	White
International Protection (IP) code	IP66
Type	IP security camera
Certification	FCC, CE, UL, IEC/EN 61000, IEC/EN 55022, IEC/EN 55024, IEC /EN60950-1
Languages support	BUL, CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HRV, HUN, ITA, JPN, KOR, LAT, LIT, NOR, POL, POR, RUM, RUS, SER, SLK, SLV, SWE, THA, TUR, VIE
Alarm input/output	Yes
Number of languages	32
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Sustainability certificates	RoHS
Operating temperature (T-T)	-30 - 65 °C
Operating relative humidity (H-H)	0 - 90 %
AC input voltage	36 - 57 V
DC output current	1 A
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	8 W
Number of cameras	1
Wi-Fi	No
Number of users	32 user(s)
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
Number of simultaneous live view channels	20 channels
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Total megapixels	3 MP
Maximum resolution	2048 x 1536 pixels
Video compression formats	H.264, H.264+, H.265, H.265+, M-JPEG
Noise reduction technology	3D noise reduction
Pan range	0 - 350 °
Pan speed	60 °/sec
White balance	ATW, Auto, Daylight, Indoor, Manual, Outdoor, Sodium lamp
Tilt angle range	0 - 90 °
Camera shutter speed	1/1 - 1/10000 s
Minimum illumination	0.01 lx
Signal-to-Noise Ratio (SNR)	52 dB
Digital zoom	16 x
Optical zoom	4 x
Focal length range	2.8 - 12 mm
Maximum aperture number	2.7
Minimum aperture number	1.6
Sensor type	CMOS
Optical sensor size	1/2.8 \

Weight and Dimensions

Height	107.2 mm
Weight	950 g
Diameter	140.7 mm
