Digital Video Recorder User Manual
42
1.5 Rear Panel
The rear panel vaires according to different models. Please refer to the actual product. The
following figures are for reference only.
Rear Panel 1:
Figure 1-11 Rear Panel of DS-7100
Table 1-10 Description of Rear Panel
BNC interface for HDTVI, and analog video input.
HDMI video output connector.
DB15 connector for VGA output. Display local video
output and menu.
Universal Serial Bus (USB) port for additional devices.
To Next Page
