User Manual of Network Video Recorder
133
9.1 Configuring General Settings
Purpose:
Network settings must be properly configured before you operate NVR over network.
Steps:
1. Enter the Network Settings interface.
Menu > Configuration > Network
2. Select the General tab.
DS-7600NI-SN
Other Models
Figure 9. 1 Network Settings Interface
 The DS-7104NI-SL/W model provides LAN and WLAN for selection on the network settings interface.
 A 10 /100 Mbps self-adaptive Ethernet interface for DS-7604/7608NI, DS-7104/7108NI and
DS-7100NI-SL series NVR; and a 10 /100/1000 Mbps self-adaptive Ethernet interface for other models.
3. In the General Settings interface, you can configure the following settings: Working Mode, NIC Type, IPv4
Address, IPv4 Gateway, MTU and DNS Server.
If the DHCP server is available, you can click the checkbox of DHCP to automatically obtain an IP address
and other network settings from that server.
 For the DS-7600NI-SE/N(P) series NVR which has the PoE or built-in switch network interfaces, the
internal NIC IPv4 address should be configured for the cameras connecting to the PoE or built-in
