HIKVISION DS-7104NI-SL/W User Manual

User Manual of Network Video Recorder
77
5.5 Configuring VCA Triggered Recording
Purpose:
Perform the following steps to set the VCA alarm and trigger recording of related cameras.
Steps:
1. Enter VCA Alarm interface of Camera Management and select a camera you want to detect VCA alarm.
Menu> Camera> VCA
The selected camera must support the VCA function.
Figure 5. 16 VCA Alarm Setting Interface
2. Check the Enable VCA Alarm checkbox and click Settings button to set up its alarm response actions.
Figure 5. 17 VCA Alarm Handling
3. Select the channels which you want the motion detection event to trigger recording.
4. Click Apply to save the settings.
5. Edit the VCA Alarm Record Schedule. For the detailed information of schedule configuration, see Chapter
Configuring Recording Schedule.
