HIKVISION DS-7104NI-SL/W User Manual

User Manual of Network Video Recorder
75
5.4 Configuring Alarm Triggered Recording
The alarm triggered recording is not supported by the DS-7100NI-SL(/W) series NVR.
Purpose:
Follow the procedure to configure alarm triggered recording.
Steps:
1. Enter the Alarm setting interface.
Menu> Configuration> Alarm
Figure 5. 12 Alarm Settings
2. Click Alarm Input tab and set the alarm parameters.
Figure 5. 13 Alarm Settings- Alarm Input
1) Select Alarm Input number and configure alarm parameters.
2) Choose N.O (normally open) or N.C (normally closed) for alarm type.
3) Check the checkbox for Enable.
4) Click Settings.
