Digital Video Recorder User Manual
251
Step 5 Click the Upgrade button to start upgrading.
Step 6 After the upgrading is complete, reboot the DVR to activate the new firmware.
16.5.2 Upgrading by FTP
Before you start
Configure PC (running FTP server) and DVR to the same Local Area Network. Run the 3
rd
-party
TFTP software on the PC and copy the firmware into the root directory of TFTP.
Step 1 Enter the Upgrade interface.
Menu > Maintenance > Upgrade
Step 2 Click the FTP tab to enter the Local Upgrade interface, as shown in Figure 16-8.
Figure 16-8 FTP Upgrade Interface
Step 3 Enter the FTP Server Address in the text field.
Step 4 Click the Upgrade button to start upgrading.
Step 5 After the upgrading is complete, reboot the DVR to activate the new firmware.
16.6 Restoring Default Settings
Step 1 Enter the Default interface.
Menu > Maintenance > Default
Figure 16-9 Restore Defaults
Step 2 Select the restoring type from the following three options.
Restore Defaults: Restore all parameters, except the network (including IP address, subnet
mask, gateway, MTU, NIC working mode, default route, server port, etc.) and user account
parameters, to the factory default settings.

HIKVISION DS-7204HGHI-F1 Specifications

General

Voltage	12 V
Product color	Black
Rack capacity	1U
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Video input channels	4 channels
USB 2.0 ports quantity	2
Power consumption (typical)	8 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	1000 g
Dimensions (WxDxH)	260 x 222 x 45 mm
