Digital Video Recorder User Manual
119
2) Click Apply to save the settings.
3) Click OK to back to the upper level menu.
Step 3 Enter the Record setting interface.
Menu> Record> Parameters
1) Select the Record tab.
2) Select Camera you want to configure.
3) Click More Settings button.
Figure 5-30 More Settings
4) Check the checkbox of Redundant Record.
5) Click OK to save the settings.
6) If the encoding parameters can also be used to other channels, click Copy and choose the
channel you want to apply the settings.
5.9 Configuring HDD Group
Purpose
You can group the HDDs and save the record files in certain HDD group.
Step 1 Enter HDD setting interface.
Menu>HDD>Advanced
Step 2 Select Storage Mode tab.
Check whether the storage mode of the HDD is Group. If not, set it to Group. For detailed
information, please refer to Chapter 14.3 Managing HDD Group.
Step 3 Select General in the left bar.
Click to enter editing interface.
