Digital Video Recorder User Manual
75
Figure 2-44 Password Configuration of the Camera
Step 5 Click OK to save the settings and exit the interface.
2.8 Viewing Signal Input Status
The Single Input Status interface is only available for DS-7200HUHI-F/S series DVR.
Purpose
For DS-7200HUHI-F/S series DVR, you can view the analog signal input channels and types and the
connectable maximum IP camera number, and configure 5MP long distance transmission.
Step 1 Enter the Signal Input Status interface.
Menu > Camera > Signal Input Status
Figure 2-45 View Signal Input Type (2)
Step 2 View the analog signal input channels and types, and the connectable maximum IP camera
number.
Step 3 (Optional) You can enable 5 MP Long Distance Transmission for the Turbo HD and AHD
signal input. Follow the steps below to enable the function.
1) Click to enter the 5 MP Long Distance Transmission Settings interface.
