HIKVISION DS-7208HQHI-K2/P User Manual

Digital Video Recorder User Manual
115
Chapter 7 Backup
7.1 Backing up Record Files
Before you start
Please insert the backup device(s) into the device.
7.1.1 Backing up by Normal Video/Picture Search
Purpose
The record files or pictures can be backed up to various devices, such as USB devices (USB flash
drives, USB HDDs, USB writer), SATA writer and e-SATA HDD.
Backup using USB flash drives and USB HDDs
Step 1 Go to Menu > Export > Normal/Picture.
Step 2 Select the cameras to search.
Step 3 Set search condition and click Search button to enter the search result interface.
Figure 7-1 Normal Video Search for Backup
Step 4 The matched video files are displayed in Chart or List display mode.
Click to play the record file if you want to check it.
Check the checkbox before the video files you want to back up.

HIKVISION DS-7208HQHI-K2/P Specifications

General

HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Number of HDDs supported	2
Power consumption (typical)	60 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
BNC input ports	1
Video input channels	8 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	17480 g
Dimensions (WxDxH)	380 x 320 x 48 mm
