HIKVISION DS-7208HQHI-K2/P User Manual

Digital Video Recorder User Manual
177
12.3.2 Exporting Network Packet
Purpose
By connecting the DVR to network, the captured network data packet can be exported to USB-flash
disk, SATA and other local backup devices.
Step 1 Go to Menu > Maintenance > Net Detect > Network Detection.
Step 2 Select the backup device from the drop-down list of Device Name.
Click the Refresh button if the connected local backup device cannot be displayed. When it fails to
detect the backup device, please check whether it is compatible with the DVR. You can format the
backup device if the format is incorrect.
Figure 12-22 Export Network Packet
Step 3 Click the Export button to start exporting.
Step 4 After the exporting is complete, click OK to finish the packet export.
Figure 12-23 Packet Export Attention
Up to 1M data can be exported each time.
12.3.3 Checking Network Status
Purpose
You can also check the network status and quick set the network parameters in this interface.
Step 1 Go to Menu > Maintenance > Net Detect > Network Detection.
Step 2 Click Status on the right bottom of the interface.

HIKVISION DS-7208HQHI-K2/P Specifications

General

HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
Number of HDDs supported	2
Power consumption (typical)	60 W
Voltage	12 V
Product color	Black
Audio output channels	1.0 channels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
BNC input ports	1
Video input channels	8 channels
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN	Yes
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	17480 g
Dimensions (WxDxH)	380 x 320 x 48 mm
