Digital Video Recorder User Manual
143
Chapter 10 VCA Alarm
Purpose
The DVR can receive the VCA alarm (line crossing detection, intrusion detection, sudden scene
change detection and audio exception detection) sent by analog camera, and the VCA detection
must be enabled and configured on the camera settings interface first. All other VCA detection
features must be supported by the connected IP camera.

The DS-7100 series DVR do not support the VCA alarm.

DS-7200HUHI series support line crossing detection and intrusion detection of all channels,
and 2-ch sudden scene change detection. Channels with audio support audio exception
detection.

DS-7200HQHI series support 4-ch line crossing detection and intrusion detection.
DS-7216HQHI series also support 1-ch sudden scene change detection. Channels with audio
support audio exception detection.

DS-7300HQHI-K series support 4-ch line crossing detection and intrusion detection, and
1-ch sudden scene change detection. Channels with audio support audio exception
detection.

For the analog channels, the line crossing detection and intrusion detection conflict with
other VCA detection such as sudden scene change detection, face detection and vehicle
detection. You can only enable one function.
10.1 Face Detection
Purpose
Face detection function detects the face appears in the surveillance scene, and some certain
actions can be taken when the alarm is triggered.
Step 1 Go to Menu > Camera > VCA.
Step 2 Select the camera to configure the VCA.
You can check the checkbox of Save VCA Picture to save the captured pictures of VCA
detection.

HIKVISION DS-7216HQHI-K1 Specifications

General

Product color	Black
Channels quantity	16 channels
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768, 3840 x 2160, 2560 x 1440
Audio input	RCA
BNC input ports	16
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	25 W
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
