HIKVISION DS-7216HQHI-K1 User Manual

Digital Video Recorder User Manual
180
Chapter 13 HDD Management
13.1 Initializing HDDs
Purpose
A newly installed hard disk drive (HDD) must be initialized before it can be used with your DVR.
Step 1 Go to Menu > HDD > General.
Figure 13-1 HDD Information Interface
You can view the Total Capacity, Free Space and Remaining Recording Time of the HDD. The
algorithm of the Remaining Recording Time is to use average bit rate for the channel
enabling smart encoding to raise accuracy.
Step 2 Select HDD to be initialized.
Step 3 Click the Init button.
Figure 13-2 Confirm Initialization
Step 4 Select the OK button to start initialization.

HIKVISION DS-7216HQHI-K1 Specifications

General

Product color	Black
Channels quantity	16 channels
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768, 3840 x 2160, 2560 x 1440
Audio input	RCA
BNC input ports	16
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (typical)	25 W
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB

Weight and Dimensions

Weight	2000 g
Dimensions (WxDxH)	315 x 242 x 45 mm
