HIKVISION DS-7600NI Series User Manual

User Manual of DS-7600NI Series NVR
54
4. Click to save the pattern.
4.2.6 Calling Patterns
Purpose:
Follow the procedure to move the PTZ camera according to the predefined patterns.
Calling pattern in the PTZ setting interface
Steps:
1. Enter the PTZ Control interface.
Menu>Camera>PTZ>More Settings
2. Select the pattern number.
3. Click , then the PTZ moves according to the pattern. Click to stop it.
Call pattern in live view mode
Steps:
1. In the live view mode, press PTZ control on the front panel or on the remote control, or click PTZ Control
icon on the quick setting toolbar.
2. And then choose Pattern on the control bar.
3. Double click the pattern or select the pattern and click to call it.
Figure 4. 11 PTZ Toolbar- Pattern
