HIKVISION DS-7608NI-Q1 User Manual

Network Video Recorder User Manual
106
The playing speed of 256X is supported.
6.1.3 Playing back by Smart Search
Purpose
The smart playback function provides an easy way to get through the less effective information.
When you select the smart playback mode, the system will analyze the video containing the
motion, line or intrusion detection information, mark it with green color and play it in the normal
speed while the video without motion will be played in the 16-time speed. The smart playback
rules and areas are configurable.
Step 1 Enter Playback interface.
Menu>Playback
Step 2 Select the Normal/Smart in the drop-down list on the top-left side.
The main stream or sub stream for recording is configurable in Menu>Record>Parameters.
Step 3 Select a camera in the camera list.
Step 4 Select a date in the calendar and click the button on the left toolbar to play the video
file.
Figure 6-6 Playback by Smart Search
Step 5 Click the radio button to switch to the playback by smart search.

HIKVISION DS-7608NI-Q1 Specifications

General

Two-way talk	Yes
Input bandwidth	80 Mbit/s
Number of users	64 user(s)
Maximum resolution	4096 x 2160 pixels
Video input channels	8 channels
Supported resolutions	4096 x 2160, 3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 720
Audio formats supported	G.711 A-law, G.711 μ-law, G.726
Video formats supported	H.264, H.264+, H.265, H.265+, MPEG4
Wi-Fi	No
HDD capacity	- GB
HDD interface	SATA
Maximum storage capacity	8 TB
Number of HDDs installed	0
Number of HDDs supported	1
USB 2.0 ports quantity	2
Ethernet LAN data rates	10, 100 Mbit/s
Supported network protocols	TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Output voltage	12 V
Power consumption (typical)	10 W
Certification	FCC Part 15 Subpart B, ANSI C63.4-2014 CE EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035:
Product color	Black
Rack capacity	1U

Weight and Dimensions

Depth	240 mm
Width	320 mm
Height	48 mm
Weight	1000 g
