User Manual of DS-9600/8600/7700/7600 Series NVR
72
Figure 5. 7 Recording Schedule Interface
You can click the button to set the accurate time of the schedule.
II. To schedule an all-day recording, check the checkbox after the All Day item.
Figure 5. 8 Edit Schedule
III. To arrange other schedule, leave the All Day checkbox blank and set the
Start/End time.
Note: Up to 8 periods can be configured for each day. And the time periods can’t be overlapped
each other.
Repeat the above edit schedule steps to schedule recording or capture for other days in the week.
If the schedule can also be applied to other days, click Copy.
Figure 5. 9 Copy Schedule to Other Days
IV. Click OK to save setting and back to upper level menu.
V. Click Apply in the Record Schedule interface to save the settings.
Draw the schedule:
Click on the color icons, you can choose the schedule type as normal or event.
