HIKVISION DS-KD-DIS User Manual

Figure 3-8 RS-485 Card Reader Wiring
4 Installaon
Note
●
Make sure the device in the package is in good condion and
all the assembly parts are included.
●
Sub module must work along with the main unit.
●
The PMR module is equipped with indicators so that it doesn't
have to be used with indicator sub module.
●
Set the sub module address before start the installaon steps.
●
Make sure the place for surface mounng is at.
●
Make sure all the related equipment is
power-o during the
installaon.
●
Tools that you need to prepare for installaon:
Drill (ø6), cross screwdriver (PH1*150 mm), and gradienter.
4.1 Congure Sub Module Address
You need to set the sub module address via DIP switch before
installaon.
Steps
1. Remove the rubber cover on the rear panel of the sub module
to expose the DIP switch.
Figure 4-1 DIP Switch
12
