A. Relevant Instrucons for External
Power Supply and Wiring of 2-wire
Video Intercom Products (2020-1-20)
Power Descripon
2-Wire Distributor
DS-KAD706
CH6 CH1 to CH5
16 W 6 W
DS-KAD704
CH4 CH1 to CH3
16 W 6 W
Modular Door Staon
The main module & the sub-module maximum power
consumpon.
Model
Stable Power Consumpon
DS-KD8003-IME2 4 W
DS-KD-KK 0.8 W
DS-KD-KP 1 W
DS-KD-DIS 2.5 W
DS-KD-E 0.8 W
DS-KD-M 0.8 W
DS-KD-INFO 1.5 W
DS-KD-PMR 8 W, 6 W or 4 W adjustable
Indoor Staon
Model
Stable Power Consumpon
DS-KH6320-WTE2 6 W
Example of the Calculaon Model of the Modular
Door Staon Sub-Module
The sum of the power consumpon of each module must be less
than the total power
consumpon of the power supply.
2-Wire
Model
DS-
KD8003-
IME2
DS-KD-
DIS
DS-KD-KP DS-KD-M /
Quanty 1 1 2 2 /
Power 4 W 2.5 W 2 W 1.6 W
Total:
10.1 W
85
