HIKVISION DS-KH8301-WT Quick Start Guide

Video Intercom Indoor Station·Quick Start Guide
14
4 Before You Start
For the first time use of the device, you are required to activate the device and set the
device password. You can activate the device on the UI, via internet with Batch
Configuration Tool, or with iVMS-4200 client software.
To activate the device on the UI, refer to chapter 5 and enter the
configuration password.
To activate the device with Batch Configuration Tool or iVMS-4200, refer
to 6.1 and the user manual in the disk.
To configure the key parameters of device on the user interface of indoor station, you
are required to input the admin password.
 The default admin configuration password is 888999.
 The default unlocking password and arming/disarming password are 123456;
 The default duress code is 654321.
You must change these default credentials to protect against unauthorized access to the
product. Please refer to the user manual for changing passwords.

HIKVISION DS-KH8301-WT Specifications

General

Color	Yes
Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Proper use	Indoor
Control type	Touch
Product color	White
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP
Outdoor unit included	No
Operating system installed	Linux
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Megapixel	0.3 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
