HIKVISION DS-KH8301-WT Quick Start Guide

Video Intercom Indoor Station·Quick Start Guide
23
5. Press the tab to save the settings.
 Enable DHCP function to obtain an IP address automatically.
 Enable Same LAN function if indoor stations and indoor extensions are in the same
local area network with other video intercom devices in a community, or the indoor
extensions will not work normally.
5.3.4 Adding Device
Adding Device (Indoor Station)
Purpose:
The indoor station never works alone. You can connect the main door station, IP camera,
SIP server, SCP (Security Control Panel), DVR/DVS/NVR, and so on. Once connected,
those devices can work together as a whole video intercom system.
 The DS-KH6210-L indoor station does not support adding IP camera, DVR/DVS/NVR,
or doorphone.
 Connecting the main door station and adding IP camera will be introduced in the
Quick Start Guide. For further information about SIP server setting, SCP (security
control panel) settings, DVR/DVS/NVR settings, and doorphone settings, please refer
to the user manual in the disk.
 Connecting Main Door Station
Steps:
1. Get to the configuration interface: Settings > Configuration, and enter the admin
password (configuration password).
2. Press the Device tab to enter the device management interface.
3. Press the Main Door Station tab to pop up the device information dialogue box.

HIKVISION DS-KH8301-WT Specifications

General

Color	Yes
Video codecs	H.264
Certification	FCC, IC, CE, C-TICK, ROHS, REACH, WEEE
Connectivity technology	Wired
Sustainability certificates	RoHS
Voice codecs	G.711u
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	LCD/TFT
Proper use	Indoor
Control type	Touch
Product color	White
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, RTSP
Outdoor unit included	No
Operating system installed	Linux
Operating relative humidity (H-H)	10 - 90 %
Main monitor station operating temperature (T-T)	-10 - 55 °C
Indoor unit power type	AC/DC
Power consumption (typical)	10 W
Megapixel	0.3 MP
Sensor type	CMOS
Maximum frame rate	30 fps
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB

Weight and Dimensions

Depth	26 mm
Width	217 mm
Height	142 mm
