HIKVISION DS-KH8350-TE1 User Manual

3.
Set SIP registraon password.
1) Tap Registraon Password.
2) Create a new SIP registraon password and conrm the password.
3) Tap OK.
4.
Oponal: Enable Compable with SIP 1.0 Indoor Staon and the indoor staon (SIP 2.0) can be
compable with SIP 1.0 indoor staon.
5.
Oponal: Enable standard SIP and you can access to the third party devices.
1) Slide to Enable Standard SIP.
2) Tap VOIP Account
Sengs and congure the account informaon, including the user name,
the phone number, the registered user name, the password, the domain, the port No., and
the
expiraon date.
Figure 3-23 VOIP Account Sengs
Note
Up to 32 characters are allowed in the user name.
3.3.6 Add Camera
Steps
1.
Tap Sengs → → Conguraon , and enter admin (acvaon) password.
2.
Tap
to enter the device management page.
3.
Tap + to pop up the dialog box.
4.
Select a protocol to add the camera.
-
Select HIK Protocol and you can add the camera depended on the HIK protocol.
Network Indoor Staon Conguraon Guide
22

HIKVISION DS-KH8350-TE1 Specifications

General

Color	Yes
Certification	FCC, IC, CE, C-TICK, REACH, WEEE, UL, CB, RCM
Connectivity technology	Wired
Sustainability certificates	RoHS
Number of displays supported	-
Voice codecs	G.711u
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Power consumption	200 mA
Indoor unit power type	DC
Power consumption (typical)	7 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	IPS
Proper use	Indoor
Product color	Black, Grey
Placement supported	Horizontal
Package weight	786 g
Outdoor unit included	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, SIP, RTSP

Weight and Dimensions

Depth	22.4 mm
Width	180 mm
Height	140 mm
Weight	600 g
