HIKVISION DS-KH8350-TE1 User Manual

Appendix A. Relevant Instrucons for External
Power Supply and Wiring of 2-wire Video Intercom
Products (2020-1-20)
Power Descripon
2-Wire Distributor
DS-KAD706 CH6 CH1 to CH5
16 W 6 W
DS-KAD704 CH4 CH1 to CH3
16 W 6 W
Modular Door Staon
The main module & the sub-module maximum power consumpon.
Model
Stable Power Consumpon
DS-KD8003-IME2 4 W
DS-KD-KK 0.8 W
DS-KD-KP 1 W
DS-KD-DIS 2.5 W
DS-KD-E 0.8 W
DS-KD-M 0.8 W
DS-KD-INFO 1.5 W
Indoor Staon
Model
Stable Power Consumpon
DS-KH6320-WTE2 6 W
Example of the Calculaon Model of the Modular Door Staon Sub-Module
The sum of the power consumpon of each module must be less than the total power
consumpon of the power supply.
Network Indoor Staon Conguraon Guide
69

HIKVISION DS-KH8350-TE1 Specifications

General

Color	Yes
Certification	FCC, IC, CE, C-TICK, REACH, WEEE, UL, CB, RCM
Connectivity technology	Wired
Sustainability certificates	RoHS
Number of displays supported	-
Voice codecs	G.711u
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Power consumption	200 mA
Indoor unit power type	DC
Power consumption (typical)	7 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
Display diagonal	7 \
Touchscreen type	Capacitive
Display resolution	1024 x 600 pixels
Display technology	IPS
Proper use	Indoor
Product color	Black, Grey
Placement supported	Horizontal
Package weight	786 g
Outdoor unit included	No
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Ethernet LAN (RJ-45) ports	1
Supported network protocols	TCP/IP, SIP, RTSP

Weight and Dimensions

Depth	22.4 mm
Width	180 mm
Height	140 mm
Weight	600 g
