HIKVISION DS-KM9503 User Manual

4 Local Operaon
4.1 Call Sengs
4.1.1 Call Resident
Call the indoor staon via the main staon.
Steps
1.
Tap Call →
to enter the call page.
Figure 4-1 Call Page
2.
Enter the calling number to call.
Note
•
The calling number format should be x-x-x-xxx. For example, the calling
number of Community 1, Building 2, Unit 3, and Room 405 is 1-2-3-405. Tap
the call buon to start an audiovisual call.
•
The community No. can be omied.
4.1.2 Receive Call
The main staon can receive the call from the indoor staon, the door staon, and
the other main staon.
Video Intercom Main
Staon Operaon Guide
11

HIKVISION DS-KM9503 Specifications

General

Product color	Black, Grey
Display diagonal	10.1 \
Touchscreen type	Capacitive
Display resolution	1280 x 800 pixels
Display technology	IPS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	2
Supported network protocols	TCP/IP, SIP, RTSP
Video codecs	H.264
Number of buttons	3 buttons
Connectivity technology	Wired
Number of displays supported	-
Megapixel	2 MP
Viewing angle, vertical	48.1 °
Viewing angle, horizontal	64.1 °
Voice codecs	G.711a, G.711u
Compatible memory cards	SD
Package weight	2305 g
Power consumption (typical)	12 W

Weight and Dimensions

Depth	166 mm
Width	292 mm
Height	31 mm
Weight	1285 g
