HIKVISION iDS-2CD9136-AIS User Manual

Network Traffic Camera • User Manual
80
 Sensitivity: Enter the sensitivity.
 Angle: Enter the angle of the radar and the horizontal direction according to the actual
application.
 Linearity Correction: You may need to adjust the radar output result according to the actual
speed.
 Constant Correction: In order to improve the accuracy of the detection speed, there is a
constant correction, which is the extra added/ minus speed value.
The final speed is the calculated according to the radar output speed, the linearity correction, and
constant correction together.
Example: The speed detected is 80km/h, and you set the linearity correction coefficient as 1.2, and
the constant correction as 5, then the final speed is 80km/h*1.2+5=101km/h. And if you do not
want to make any change to the detected speed, you can set the linearity correction coefficient as
1, and the constant correction as 0.
(Optional) Copy the configuration of current lane to other lanes.
Click Save to save the settings.
You can click the Default button to restore the parameters to default values.

HIKVISION iDS-2CD9136-AIS Specifications

General

Aperture	F1.6
IR Range	Up to 30 m
Bit Rate	32 Kbps to 16 Mbps
Alarm Input	1 channel
Alarm Output	1 channel
Ingress Protection	IP67
Wide Dynamic Range (WDR)	120 dB
Sensor Type	CMOS
Lens	2.8 mm
Minimum Illumination	0.01 Lux @ (AGC ON)
Video Compression	H.265/H.264
Audio Compression	G.711/G.726
Audio Input	1 channel
Audio Output	1 channel
Communication Interface	1 RJ45 10M/100M Ethernet port
On-board storage	Micro SD/SDHC/SDXC card, up to 256 GB
Operating Conditions	-30 °C to 60 °C (-22 °F to 140 °F), Humidity ≤ 95% (non-condensing)
Power Supply	12 VDC ± 25%
Weight	0.5 kg
Day & Night	IR cut filter

Summary

LEGAL DISCLAIMER

Regulatory Information

FCC Information

Details FCC compliance rules and conditions for the device operation.

EU Conformity Statement

States compliance with EU directives and provides recycling information.

Safety Instructions

Preventive and Cautionary Tips

Chapter 1 Network Connection

1.2 Activate the Camera

Chapter 2 Login

Chapter 3 Live View

Chapter 4 Picture Search

Chapter 5 Local Configuration

Chapter 6 System Configuration

6.4 Configure Network Parameters

Configures network settings, including IPv4 and IPv6 addresses, subnet masks, and gateways.

6.7 Configure Time

Configures time settings, including manual adjustment and NTP synchronization.

Chapter 7 Encoding and Storage Configuration

7.1 Configure Video Encoding

Sets parameters for video streams, including bitrate, resolution, and encoding.

7.4 Configure Record Schedule

Sets up scheduled recording times and overwriting behavior.

7.5 Configure Storage Management

Manages storage, formats TF cards, and views storage information.

7.6 Configure FTP

Sets up FTP server details for uploading captured pictures.

Chapter 8 Text Overlay Configuration

8.1 Configure Capture Picture Overlay

Sets overlay parameters like font size, color, and position for captured pictures.

8.2 Configure OSD Settings

Configures general OSD attributes, size, alignment, and display items.

Chapter 9 Capture Parameters Configuration

9.1 Configure License Plate Parameters

Sets up license plate recognition settings for capturing plate numbers.

9.2 Configure Flash Light Parameters

Configures parameters for controlling the camera's flashlight.

9.5 Configure Vehicle Feature

Configures various vehicle feature detection settings like color, logo, and face matting.

Chapter 10 Image Parameters Configuration

10.2 Configure General Parameters

Configures general image settings like saturation, sharpness, white balance, and brightness.

10.3 Configure Video Image

Configures video image parameters like brightness, contrast, shutter speed, and DNR.

10.4 Configure Record

Configures image parameters for recorded video, such as brightness and shutter speed.

Chapter 11 Application Mode Configuration

11.1 Mixed-traffic Lane

Configures the camera for mixed-traffic analysis, including video and radar speed detection.

11.2 Video Analysis E-Police

Configures the camera for video analysis in e-police mode for traffic violations.

11.5 RS-485 Radar

Configures RS-485 radar for high-accuracy speed detection.

Chapter 12 Exception

Chapter 13 Maintenance

13.2 User Management

Manages user accounts, permissions, and security settings.

13.9 Upgrade the System

Upgrades the camera's firmware to the latest version.
