CPU 03 3 Product Description
HI 800 479 E Rev. 1.00 Page 17 of 38
3.4.6 Communication
The Ethernet interfaces and fieldbus interfaces of the CPU 03 module are used to
communicate with external systems.
The controller communicates with remote I/Os via safeethernet. Up to 128 redundant
safeethernet connections can be configured.
i
When configuring safety-related communication, observe the instructions specified in the
SILworX Communication Manual.
3.4.6.1 Connections for Ethernet Communication
Property Description
Ports 4
Transfer standard 10/100/Base-T, half and full duplex
Auto negotiation Yes
Auto crossover Yes
IP address Freely configurable
1)
Subnet Mask Freely configurable
1)
Supported protocols
Safety-related: safeethernet, PROFIsafe
Standard protocols: Programming and debugging tool (PADT),
OPC, Modbus TCP, TCP SR, SNTP, ComUserTask,
PROFINET
1)
The general rules valid for assigning IP address and subnet masks must be adhered to.
Table 8: Connections for Ethernet Communication
The 4 RJ-45 connectors with integrated LEDs are located on the front plate of the module.
Refer to Chapter
3.4.3.3 for a description of the LEDs' function.
The connection parameters are read based on the MAC address (media access control
address) defined during manufacturing.
The MAC address of the module is specified on the label on the rear side of the printed
circuit board. The first MAC address applies for the COM module on the CPU module, the
second for the switch.
Examples of label: MAC-ADR1: 00.E0.A1.00.0E.04 (COM)
MAC ADR2: 00.E0.A1.00.0E.05 (switch)
