CPU 03 4 Start-up
HI 800 479 E Rev. 1.00 Page 25 of 38
4.4.1.2 Tab: Routings
The Routings tab contains the following parameters:
Parameter Description
Name Denomination of the routing settings
IP Address
Target IP address of the communication partner (with direct host
routing) or network address (with subnet routing).
Range of values: 0.0.0.0...255.255.255.255
Default value: 0.0.0.0
Subnet Mask Define the target address range for a routing entry.
255.255.255.255 (with direct host routing) or subnet mask of the
addressed subnet.
Range of values: 0.0.0.0...255.255.255.255
Default value: 255.255.255.255
Gateway IP address of the gateway to the addressed network.
Range of values: 0.0.0.0...255.255.255.255
Default value: 0.0.0.1
Table 17: Routing Parameters of the CPU and COM
4.4.1.3 Tab: Ethernet Switch
The Ethernet Switch tab contains the following parameters:
Parameter Description
Name
Name of the port (Eth1...Eth4) as printed on the housing; per
port, only one configuration may exist.
Speed [Mbit/s] 10 Mbit/s: Data rate 10 Mbit/s
100 Mbit/s: Data rate 100 Mbit/s
1000 Mbit/s: Data rate 1000 Mbit/s (not supported)
Autoneg: Automatic baud rate setting
Default value: Autoneg
Flow Control Full duplex: Simultaneous communication in both directions
Half duplex: Communication in one direction
Autoneg: Automatic communication control
Default value: Autoneg
Autoneg also with Fixed
Values
The Advertising function (forwarding the speed and flow control
properties) is also performed if the parameters Speed and Flow
Control have fixed values.
This allows other devices with ports set to Autoneg to recognize
the HIMax port settings.
Default setting: Activated
Limit Limit the inbound multicast and/or broadcast packets.
Off: No limitation
Broadcast: Limit broadcast packets (128 kbit/s)
Multicast and Broadcast: Limit multicast and broadcast packets
(1024 kbit/s)
Default value: Broadcast
Table 18: Ethernet Switch Parameters
